Tri-Auger Diet Feeder

Maximise Efficiency

Designed for large-scale farming needs, the Abbey Machinery Tri-Auger Diet Feeder excels in delivering a high-quality mix quickly and efficiently. This feeder combines minimal horsepower requirements with a six-weigh bar system integrated with advanced Digi-Star technology for precise data tracking. Its narrow, manoeuvrable design, coupled with a self-steering bogie and a wide feed-outdoor, ensures rapid and effective operation. Ideal for operations seeking to maximise feeding efficiency without compromising on mobility or speed.

Three Powerful Augers: Equipped with three vertical 22mm augers for comprehensive mixing.
Precision Weighing System: Features electronic scales with six weigh bars linked to Digi-Star technology for accurate data tracking.
Enhanced Manoeuvrability: Narrow design and self-steering bogie ensure it moves smoothly around the yard.
Efficient Discharge: Wide feed-out door for rapid and efficient emptying.
Robust Drive System: COMER planetary gear drive ensures reliable performance.
Dual-Speed Capability: Includes two-speed gearboxes to adapt to different feeding needs.
Safety and Accessibility: Wide angle PTO shaft with shear bolt protection and a front access platform with folding ladder.
Enhanced Cutting: 24 knives and 2 counter knives for effective material breakdown.

Technical Specification

VF3350 Tri Auger Vertical Feeder

Model	3350SD
Overall Length (m)	9.52
Overall Height (m)	3.02
Max Overall Width (m)	2.68
Tub Height (m)	1.95
Tub Top Opening Length (m)	7.90
Discharge Height (m)	0.94
Discharge Reach Beyond Wheel (m)	0.29
Tub Base to Ground (m)	1.07
